IP67 Waterproof 78Pin D Sub Connector
  • IP67 Waterproof 78Pin D Sub Connector - 0 IP67 Waterproof 78Pin D Sub Connector - 0
  • IP67 Waterproof 78Pin D Sub Connector - 1 IP67 Waterproof 78Pin D Sub Connector - 1
  • IP67 Waterproof 78Pin D Sub Connector - 2 IP67 Waterproof 78Pin D Sub Connector - 2
  • IP67 Waterproof 78Pin D Sub Connector - 3 IP67 Waterproof 78Pin D Sub Connector - 3
  • IP67 Waterproof 78Pin D Sub Connector - 4 IP67 Waterproof 78Pin D Sub Connector - 4
  • IP67 Waterproof 78Pin D Sub Connector - 5 IP67 Waterproof 78Pin D Sub Connector - 5
  • IP67 Waterproof 78Pin D Sub Connector - 6 IP67 Waterproof 78Pin D Sub Connector - 6
  • IP67 Waterproof 78Pin D Sub Connector - 7 IP67 Waterproof 78Pin D Sub Connector - 7
  • IP67 Waterproof 78Pin D Sub Connector - 8 IP67 Waterproof 78Pin D Sub Connector - 8

IP67 Waterproof 78Pin D Sub Connector

SIGNALORIGIN® is a d sub78 connector manufacturer with many years of experience. SIGNALORIGIN® uses the highest quality parts and plating thicknesses designed to ensure the quality of D-Sub connectors. The products on the page are regular models, if you do not find the right product and need to customize, please contact us.

Send Inquiry

Product Description

Product Introduction of the IP67 Waterproof 26Pin D Sub Connector

These d sub78 connectors are the flame retardant glass-filled PBT insulator and nickel-plated machined contacts mounted in a nickel-plated or tin-plated steel housing.D-Sub High Density connectors differ from standard connectors in that D-Sub High Density connectors provide a higher density of contacts.

SIGNALORIGIN® is a China leader in providing interconnect solutions into a wide range of markets and applications, from traditional connectors to the latest and next generation technical products. We provide you with the highest quality and most cost-effective d sub78 connectors and services, and look forward to working with you!

Product Parameter (Specification) of the IP67 Waterproof 26Pin D Sub Connector

Material

Insulator material

PBT+30% G.F (UL94V-O)

Insulator color

Black/Blue (can be customized)

Contacts material

Copper  alloy

Contact plating

Gold plated on nickel

Shell material

Steel/SPCC-SD, nickel or tin plated

Electrical

Dielectric rating

300V AC

Current rating

3AMP

Contacts OD

∮0.76

Contact resistance

10mΩ Max

Insulation resistance

5000MΩ Min at 500V DC

Mechanical

Dielectric withstanding voltage

750V AC rms  at 1 minute

Insertion force

156N Max

Extraction force

15.6N Min

Durability

500 cycles

Operating temperature

-55°C ~125°C

Product details of the IP67 Waterproof 26Pin D Sub Connector

the ability to design the most fitness product for different size, appearance, application requirements.

Product drawing of the IP67 Waterproof 26Pin D Sub Connector

Raw material of the IP67 Waterproof 26Pin D Sub Connector

WHY CHOOSE US

1).Abundant industry experience with 16 years.

2).Lower price and delivery on time.

3).Strict test for high quality product.

4).3-5 free samples for our clients.

5).All of our products meet the UL requires)

FAQ

1).If I want to customize products, how will it work?

Please provide drawings or pictures, We will have professional engineers to connect with you. OEM service is welcome.


2) .How to choose the right D-SUB connector for my application?

When choosing the right D-subminiature connector , there are a variety of factors to take into consideration, including operating conditions, housing materials, and pin type. All of these aspects will affect and enable the right configuration for your chosen application.


3).What is your warranty?

Our warranty is 12 months after delivery, Signalorigin pays high attention to after-sales service.


4)What are the advantages and disadvantages of a D-Sub Connector?

D-Subs are being utilised less on modern devices like laptops, monitors and televisions where physical depth and weight are important to the user. D-Sub connectors take much longer to plug in and unplug due to their size and termination, unlike USB and HDMI connectors.The advantages of D-Sub Connectors are they are extremely rugged and can be used in harsh environments. They are small enough to fit into tight spaces and have a long-life cycle. They are diverse and work well within many different industries .


5) .What's your delivery time?

5-7 working days for samples, 20-35 working days for bulk order.
