M12 4 Pin Circular Connector

M12 4 pin can be used for industrial machinery, automation systems, automotive electronics, and other applications. We manufactured these connectors with high-quality materials to withstand harsh environments. They can ensure uninterrupted signal transmission and power delivery, even in the most demanding conditions.

Send Inquiry

Product Description

Product Introduction of the M12 4 Pin Circular Connector

M12 4 pin circular electrical connectors wholesale. SIGNALORIGIN can help provide circular interconnect solutions that are engineered for your needs. SIGNALORIGIN connectors offer you the reliable and easy to install solution for your requirements. Whether you need to connect power, signal or data – or all combined – these connectors provide a customized solution for your application.

Product Parameter (Specification) of the M12 4 Pin Circular Connector

Material

Insulator material

PBT+30% G.F (UL94V-O)

Insulator color

Black/Blue (can be customized)

Contact plating

Gold plated

Shell material

Steel/SPCC-SD, nickel or tin plated

Electrical

Dielectric rating

120V AC

Current rating

5AMP

Contact resistance

30mΩ Max

Insulation resistance

1000MΩ Min at 500V DC

Mechanical

Dielectric withstanding voltage

750V AC rms  at 1 minute

Durability

500 cycles

Operating temperature

-40°C ~125°C

Product Feature of the M12 4 Pin Circular Connector

More than 1,000 customer co-operation cases.

One-stop supplier, various types of connectors for your choice.

Product Details of the M12 4 Pin Circular Connector

Product Qualification of the M12 4 Pin Circular Connector

Deliver,Shipping And Serving of the M12 4 Pin Circular Connector

FAQ

1) .What is the Minimum Order Quantity(MOQ)?

Normally, MOQ is 100pcs, but special requirements can be accepted.


2) .Are M12 connectors waterproof?

The M12 connecting interface features waterproof protection (IP65 / IP68 / IP69K), cross-manufacturer compatibility (IEC 61076-2), and multipurpose applications (Signal, Power, Network).


3) .Are all M12 connectors the same?

There are currently more than twenty different types of M12 connector coding identifiable by an alphabetical letter from A to Y. However, connectors coded A, B, C, D and X are the most frequently used.


4) .How many amps is a D-sub connector?

Standard Density D-Sub connectors are available in pin counts from 9 - 50, with typical current capacities of 5 amps per contact - enough to drive active displays, sensors, actuators and single board computers.


5) .What's your delivery time?

5-7 working days for samples, 20-35 working days for bulk order.
