D-Sub 9W4 Coaxial Connector

SIGNALORIGIN® D-Sub 9W4 Coaxial Connector wholesale. The mixed layout Combo D-sub connector combines signal, power (up to 40 Amp), and RF Combo d-sub connectors coaxial (50 and 75 Ohm) contacts within a variety of industry standard D shell sizes. This connector achieves space saving on PCB’s and I/O designs. Our complete line of D-subminiature connectors ranges from standard D-sub connectors, High density D-sub Connectors, Combo D-sub connectors, High power d sub connector, Dual port d-sub, D-sub coaxial connector and waterproof D-sub connectors and more.

Send Inquiry

Product Description

Product Introduction of the D-Sub 9W4 Coaxial Connector

SIGNALORIGIN® is a leading China D-Sub 9W4 Coaxial Connector manufacturer. 9W4 Brass Male Female High Current Connector D-SUB 5+4PIN Solder Type. 9W4 D-sub mixed contact connectors from SIGNALORIGIN is a 9W4 Combination D-sub Plug with Tin/Ni or Au finished steel shell, mixed-layout and PBT thermoplastic, 30% glass filled, UL94V-O rated insulator. Solder cup contact termination. Application in Agriculture & Construction Equipment, Harsh Environment, Machine Manufacturing, Medical, Robotics & Automation, Transportation.Application of D SUB Female 9W4 Power Connector 180° Through Hole Solder Type For PCB Mount:

medical electronics

wireless outdoor telecom systems

industrial automation

oil exploration

printers and displays

diagnostic systems

Product Parameter (Specification) of the D-Sub 9W4 Coaxial Connector

Material	Insulator material	PBT+30% G.F (UL94V-O)
	Insulator color	Black/Blue (can be customized)
	Contacts material	Copper alloy
	Contact plating	Goldplated ,1U”~30U"
	Shell material	Steel/SPCC-SD, nickel or tin plated
Electrical	Dielectric rating	300V AC
	Highfrequency contacts current rating	50 or 75 ohm
	Contact resistance	2.7mΩ Max
	Insulation resistance	2000MΩ Min at 500V DC
Mechanical	Dielectric withstanding voltage	1000V AC rms at 1 minute
	Insertion force	￠1.0 :3.4 N /Pin（MAX) ￠3.6:12 N /Pin（MAX)
	Extraction force	￠1.0:0.3N /Pin MIN ￠3.6:2 N /Pin MIN
	Durability	500 cycles
	Operating temperature	-55°C～125°C
